PDA-X1602
Professional Class-D Amplifier 2x 800W
SKU 172.123
|EAN 8715693367003
New
All product information
Compare
PDA-X series
Description
Highlights
- Intelligent multifunctional digital amplifier
- High-efficiency Class-D amplifier technology
- Suitable for Hi-Z or Lo-Z (2Ω, 4Ω, 8Ω or 70V/100V)
- Soft Start and Power Factor Correction
- Compact and lightweight 1U housing
- Intelligent energy-saving design with low heat generation
- OLED display for clear status monitoring and control
- Automatic standby mode for reduced power consumption
- Reliable performance for professional installation use
- Advanced protection against short circuit, overload and overheating
- Clip and DC protection for safe long-term operation
- Designed for 19" rack mounting
Specifications
BrandPower Dynamics
Product seriePDA-X series
ColourBlack
Amplifier typePower amplifier
Output channels2
Frequency Response20 - 20,000 Hz
Impedance2 - 16 Ω, 70V, 100V
Audio specifications
Input Level: Line1.5V, 20 kOhm
THD: Main<0.1%
Amplifier specifications
Connections
Input connections
- 2x Balanced Line - 3-pin XLR (F)
- 1x Power - IEC (M)
Output connections
- 2x Balanced Line - 3-pin XLR (M)
- 2x Speaker - NL4
Environmental
IP ratingIP20
Electrical
Power Supply100-250VAC 50/60Hz
Mechanical
Rack units1U
Dimensions
- 483 x 268 x 44 mm (W x D x H)
Weight
- 5 kg
Accessories
Included Accessories
- Power cable
Manuals & Documents
Manual
PDF
